A split rail fence is a great option for a residential backyard, offering a rustic, natural look that enhances the charm of your outdoor space. This type of fence is perfect for homeowners looking to define boundaries without creating a closed-off or obstructed view. It’s an ideal choice for larger properties or rural settings, as its open design allows for easy visibility while still providing an effective barrier for pets, children, or livestock. The simple, classic structure of a split rail fence also requires minimal maintenance, making it a low-cost, long-lasting option that blends seamlessly with the landscape. Whether you're looking to add character to your yard or create a subtle boundary, a split rail fence brings both beauty and practicality to your home

• Made from hand- or machine-split logs, typically cedar or locust for natural rot resistance.

• Rails interlock into routed or notched posts, often without nails or hardware.

• Very rustic appearance—ideal for rural properties, trails, and large acreage.

• Lower material cost compared to more refined fence styles.

• Gaps between rails mean it’s more of a boundary marker than a containment fence unless paired with wire.

Rail options:

• 2-Rail (≈3 ft high): Decorative boundary or property line marker.

• 3-Rail (≈4 ft high): Most popular; good for general yard definition.

• 4-Rail (≈5 ft high): Added height for livestock or visual impact.

Vinyl Split Rail

• Constructed from PVC designed to mimic wood grain.

• Won’t rot, warp, or attract insects.

• Requires minimal maintenance—just occasional washing.

• Often reinforced with internal aluminum or steel for strength.

• Higher upfront cost but lower long-term maintenance expense.

Rail options:

• 2-Rail: Decorative front yard or commercial use.

• 3-Rail: Most popular residential option.

• 4-Rail: Taller perimeter fencing with clean, uniform look.

Post and Rail (Mortised)

• Rails fit into pre-cut holes (mortises) in square or round posts for a cleaner, structured look.

• Stronger connection points than stacked split rail.

• Often pressure-treated pine or cedar.

• Works well on level ground and gentle slopes.

• Easier to repair individual rails compared to interlocking styles.

Rail options:

• 2-Rail: Light-duty residential or decorative use.

• 3-Rail: Standard for yards and light livestock.

• 4-Rail: Common in equestrian and farm settings.

Split Rail with Wire Mesh

• Standard wood or vinyl rails combined with welded or woven wire backing.

• Prevents pets, goats, and smaller livestock from slipping through gaps.

• Mesh is typically stapled or clipped to the inside of posts.

• Keeps the open, rustic look while adding functionality.

• Ideal for dog containment or mixed-use farms.

Rail options:

• 2- or 3-Rail: Most common with wire reinforcement.

• 4-Rail: Used when additional height or animal control is required.

Round Rail

• Rails are machine-rounded for uniform diameter and smoother finish.

• Less rustic, more polished appearance.

• Typically installed with doweled ends that insert into pre-drilled posts.

• Good choice for HOA communities or landscaped properties.

• Can be stained or sealed easily due to smooth surface.

Rail options:

• 2-Rail: Budget-friendly and decorative.

• 3-Rail: Most common suburban choice.

• 4-Rail: Taller fence line for larger animals or added curb appeal.

Slip Board (Board Rail)

• Uses flat dimensional boards instead of round rails.

• Boards slide into routed channels in posts.

• Offers a more formal, estate-style appearance.

• Strong and stable—excellent for horses.

• Easier to paint or stain for a finished look.

Rail options:

• 3-Rail (≈4–4.5 ft high): Standard for horse fencing.

• 4-Rail (≈5 ft high): Extra safety and visibility for larger breeds.

Chain Link Mesh

• 16 gauge (lighter residential use)

• 14 gauge (standard residential)

• 12.5 gauge (heavy residential / light commercial)

• 11 gauge (commercial strength)

• 9 gauge (heavy commercial / high security)

Chicken Wire (Poultry Mesh)

• Lightweight hex-shaped mesh

• Good for chickens, small animals, and garden protection

Welded Wire Mesh

• Common sizes like 2"x4" or 2"x2" mesh openings

• Available galvanized or vinyl-coated (black or green)

High-Tensile Smooth Wire (Line Wire)

• Strong single or multiple strand option

• Can be used alone or added for reinforcement

Woven Wire / Field Fence

• Ideal for horses, goats, sheep, and livestock

• Flexible design follows uneven ground

Electric Wire (Single or Multiple Strands)

• Added deterrent for livestock or wildlife

• Can be installed along top or inside of fence
